KODEX-EPD RF Ablation System Towards an open-platform solution for RF ablation

KODEX-EPD RF Ablation System

Towards an open-platform solution for RF ablation

מצא מוצרים דומים

The KODEX-EPD RF Ablation System [1] is an open platform system which allows physicians to choose from a wide range of therapeutic catheters [2]. Based on the market-leading platform from Stockert, the KODEX-EPD RF Ablation System is designed for streamlined operation.

צרו איתנו קשר

Media Gallery

Features
Fully integrated system
Fully integrated system

Fully integrated system

The fully integrated system comprising of Generator, Irrigation Pump, Remote Control and Foot Pedal, supports personalized workflows and operation from the procedure or control room. Interactive displays support the user during pre-procedural system setup, displaying the status of the device connections, guiding correct loading of tubing, and indicating system readiness.
Intuitive touch screen
Intuitive touch screen

Intuitive touch screen

KODEX-EPD RF Ablation System offers an intuitive touch-screen interface featuring: • One-touch personalized settings • Real-time readings • Connection status overview screen
Dynamic flow rate
Dynamic flow rate

Dynamic flow rate

During irrigated RF ablation, the smart irrigation system, with dynamic flow rate, automatically adjusts the flow rate based on the selected RF power.

מפרטים

KODEX-EPD RFG Remote (Operating specs)
KODEX-EPD RFG Remote (Operating specs)
KODEX-EPD RFG Remote
  • System operation from ctrl room, incl, all generator and ablation parameters
KODEX-EPD RF Generator (Operating specs)
KODEX-EPD RF Generator (Operating specs)
Output modes*
  • Temperature control; Power control
Max. RF output
  • 100 W / 100 Ω
Warning/cut-off limits
  • Ablation temperature, impedance, esophageal probe temperature (and more)
KODEX-EPD RFG Pump (Physical specs)
KODEX-EPD RFG Pump (Physical specs)
Weight
  • 5.5 kg (12.1 lbs)
Dimensions (HxWxD)
  • 18 cm x 19.5 cm x 23.5 cm (7.1'' x 7.7'' x 9.3'')
Power inputs
  • 30 VA, 100-120 V / 220-230 V, 50-60 Hz
KODEX-EPD RF Generator (Physical specs)
KODEX-EPD RF Generator (Physical specs)
Weight
  • 18.5 kg (40.8 lbs)
Dimensions (HxWxD)
  • 17.8 cm x 39.9 cm x 34.4 cm (7'' x 15.7'' x 13.5'')
Power inputs
  • 350 VA, 115-120 V / 230 V, 50-60 Hz
KODEX-EPD RFG Remote (Physical specs)
KODEX-EPD RFG Remote (Physical specs)
Weight
  • 4.5 kg (9.9 lbs)
Dimensions (HxWxD)
  • 22 cm x 39.5 cm x 17 cm (8.7'' x 15.6'' x 6.7'')
Power inputs
  • 40 VA ,100-240V, 50-60 Hz
KODEX-EPD RFG Pump (Operating specs)
KODEX-EPD RFG Pump (Operating specs)
Max. Infusion pressure
  • 120 psi
Flow rate (ablation)
  • 6 mL/min – 60 mL/min (user configurable)
Flow rate (standby)
  • 1 mL/min – 5 mL/min (user configurable)
Warning/cut-off limits
  • Low fluid level, bubble warning (and more)

Documentation

Brochure (1)

Brochure

  • 1. KODEX-EPD RF Ablation System is manufactured by Stockert GmbH, Bötzinger Straße 31, 79111, Freiburg, Germany.
  • 2. For a list of compatible devices and catheters, please contact EPD Solutions. Devices and catheters that are not listed as compatible should not be connected to the KODEX-EPD RF Ablation System. For more information about this product (including user manuals or instructions for use), please contact your EPD Solutions representative.
  • Not available for sale within the United States. Available for sale in the CE mark countries only. Please contact EPD Solutions for list of countries.
  • * Ablation mode is linked to catheter type. Not all ablation modes available for each catheter type.
