GlideLight Laser sheath

GlideLight

Laser sheath

מצא מוצרים דומים

Safely and efficiently removing leads depends on tools that give you versatility and control. GlideLight laser sheath offers the unprecedented ability to customize the laser’s repetition rate throughout a procedure. At 80Hz, the GlideLight laser sheath requires up to 55% less advancement force,¹ and advance up to 62% more efficiently through tough binding sites than SLS II.²

צרו איתנו קשר

Media Gallery

Features
Versatility
Versatility

Versatility

No two lead removal procedures are the same. Each binding site is unique, lead designs vary, and every patient’s anatomy is different.
Efficiency
Efficiency

Efficiency

Stalled progression during lead removal procedures can lengthen the time they take to complete. GlideLight laser sheath may enable smoother and more consistent progression.
Control
Control

Control

Using a high degree of mechanical force when removing leads can compromise lead integrity.³⁻⁶ GlideLight laser sheath provides critical control when progressing through binding sites.⁷

מפרטים

Model Number 500-301
Model Number 500-301
Repetition rate
  • 25-80 Hz
Sheath size
  • 12 F
Maximum target lead diameter
  • 7.5 F / 0.098" / 2.50 mm
Clinical energy setting
  • 30-60 mJ/mm
Maximum tip outer diameter
  • 12.5 F / 0.164" / 4.17 mm
Minimum tip inner diameter
  • 8.3 F / 0.109" / 2.77 mm
Working length
  • 50 cm
SLS II model number 500-001
SLS II model number 500-001
Max. target lead diameter
  • 7.5 F / 0.098" / 2.50 mm
Clinical energy setting
  • 30-60 mJ/mm
Max. outer tip diameter
  • 12.5 F / 0.164" / 4.17 mm
Repetition rate
  • 20-40 Hz
Working length
  • 50 cm
Min. inner tip diameter
  • 8.3 F / 0.109" / 2.77 mm
Model Number 500-303
Model Number 500-303
Repetition rate
  • 25-80 Hz
Working length
  • 50 cm
Sheath size
  • 16 F
Minimum tip inner diameter
  • 12.5 F / 0.164" / 4.17 mm
Maximum target lead diameter
  • 11.5 F / 0.150" / 3.83 mm
Clinical energy setting
  • 30-60 mJ/mm
Maximum tip outer diameter
  • 17.2 F / 0.225" / 5.72 mm
Model Number 500-302
Model Number 500-302
Repetition rate
  • 25-80 Hz
Clinical energy setting
  • 30-60 mJ/mm
Maximum target lead diameter
  • 9.5 F / 0.124"/ 3.17 mm
Maximum tip outer diameter
  • 14.7 F / 0.192" / 4.88 mm
Sheath size
  • 14 F
Working length
  • 50 cm
Minimum tip inner diameter
  • 10.2 F /0.134" / 3.40 mm

Documentation

Brochure (2)

Brochure

  • 1. Comparison of average peak push forces required to advance Laser Sheath at 40Hz vs. 80Hz Pulse Repetition Rate through simulated fibrosis material at an advancement rate of 1.0 mm/second. D015722, Data on file at Philips
  • 2. Comparison of ablation force vs. advancement rate of Laser sheath 40Hz vs. 80Hz by use of the data collected in D015786, Data on file at Philips
  • 3. Maytin M, Epstein, L (2011). The challenges of transvenous lead extraction. Heart, 97(5): 425-34.
  • 4. Henrikson, C.A., et al. (2008). How to prevent, recognize, and manage complications of lead extraction. Part III: Procedural factors Heart Rhythm. Jul;5(7):1083-7. Epub 2007 Oct 9.
  • 5. Smith MC, Love CJ. Extraction of transvenous pacing and ICD leads. Pacing Clin Electrophysiol 2008:31:736-52.
  • 6. Wilkoff, B.L., et al. (1999). Pacemaker lead extraction with the laser sheath: Results of the Pacing Lead Extraction with Excimer Sheath (PLEXES) trial. JACC, 33(6), 1671-1676.
  • 7. Reduced advancement force lowers the forces applied to leads during extraction, D015861-01, Data on file at Philips
  • 8. Design Verification Report for Ablation Force Testing. D015722, Data on file at Philips.
  • Product availability is subject to country regulatory clearance. Please contact your local sales representative to check the availability in your country.
